TYPES	Stroke mm	L extended mm	Compression force max. N	Compression force with MBS max. N
HBS-35-100	117	487	10,000	10,000
HBS-35-150	167	637	7,500	10,000
HBS-35-200	217	787	5,150	10,000
HBS-35-300	317	1,087	2,850	10,000
HBS-35-400	417	1,387	1,800	10,000
HBS-35-500	517	1,687	1,240	10,000
HBS-35-600	617	1,987	910	8,600
HBS-35-700	717	2,287	690	6,500
HBS-35-800	817	2,587	540	5,100

Hydraulic Dampers
HBS-35-500

Direction change backlash free linear motion regulation

Adjustable, Without Free Travel
Compression force max. 1,240 N
Stroke 517 mm

Damping either in one or both directions: The hydraulic dampers of the product family HBS are made in a slim gas spring design and are compact and high in performance. Maintenance-free and ready-to-install they allow precise setting of retraction and extension speeds without any free travel when changing direction.

These hydraulic dampers offer constant feeding rates and can be finely tuned via the screw adjustment. A control segment on the piston makes the adjustment at the end position child’s play. Thanks to many add-on components the assembly is easy to mount, so that the damper can be universally deployed for damping back and forth swinging masses, such as in power or free conveyors.

Please note that the last goods issue for Christmas/New Year will be on December 23th. In the new year, outgoing goods will start again on January 2nd

This product is not available for
online order.

If you are interested in ordering this
product, click the inquiry form below
and we will contact you.

CAD Drawings

HBS-35-500

Adjustable, Without Free Travel

Dimensions

Stroke	517 mm
L extended	1,687 mm

Technical data

Compression force max. 1,240 N

Compression force with MBS max. 10,000 N

Traction force max. 10,000 N

Outer body diameter Ø 35 mm mm

Piston rod diameter Ø 14 mm

Lifetime Approx. 10,000 m

Operating temperature range -20 °C to +80 °C

Adjustment Achieved by turning the piston rod in its fully extended or fully compressed position.
Clockwise rotation = increase of the damping
Anti-clockwise rotation = decrease of the damping
Damping force adjustable before installation. The adjustment can add a max. of 5 mm to the L dimension.

Positive stop External positive stops 1 mm to 1.5 mm before the end of stroke provided by the customer.

Damping medium hydraulic oil

Material Outer body: zinc plated or coated steel; Piston rod: hard chrome plated steel; End fittings: zinc plated steel

Mounting in any position

Note

Increased break-away force if unit has not moved for some time.

End fittings

They are interchangeable and if necessary must be positively secured by the customer to prevent unscrewing.

Safety information

For long strokes with high forces use swivel mounting block MBS.

On request

Special oils, other special options and special accessories are available on request.
